Fiber Metal Laser Cut Cutting Machinery
₹170,000.00
Model No. – ST-TS3015
Fiber Metal Laser Cut Cutting Machinery
Quick Technical
- Dimension – 4600*2450*1700mm
- Laser Power – 1KW
- Working area for metal sheet – 3060*1530mm
- Max running speed – 90m/min
- Continuous working time – 24h
Description
Applicable Materials :
Fiber Laser Cutting Equipment is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc.
technical fact
| Model | ST-TS3015 |
| Dimension | 4600*2450*1700mm |
| Laser power | 1KW |
| Working area for metal sheet | 3060*1530mm |
| Y-axis stroke | 3000mm |
| X-axis stroke | 1500mm |
| Z-axis stroke | 120mm |
| X/Y axis position accuracy | ±0.03mm |
| X/Y axis reposition accuracy | ±0.02mm |
| Max running speed | 90m/min |
| Maximum acceleration | 1.0G |
| Specified voltage and frequency | 380V/50Hz/60Hz/60A |
| Continuous working time | 24h |
| The Best Working Temperature | 10-35℃ |
SAMPLES OF PRODUCTS
Product Samples Cutting
through STRADE Laser Cutting Machines
get a quotes
Share your Requirements with STRADEHUB Laser
Our Sales team will Contact you shortly with best offer rates.
components & EQUIPMENT DETAILS
